目鏡 Eyepiece |
大視野 WF10X視場數中22mm)Wide feld WF10X(feld number:$22mm) |
||
|
無限遠平場消色差物鏡 Infinity planachromatic objective |
DZ-8(配明場物鏡) Equipped with bright feld objectives |
PLL10X0.25 工作距離:5 mm PLL10X0.25(Work distance):5 mm |
|
|
PLL20X0.40 工作距離:8.80 mm PLL20X0.40(Work distance):8.80 mm |
|||
|
PLL50X0.70 工作距離:3.68 mm PLL50X0.70(Work distance):3.68 mm |
|||
|
PLL100X0.85(干式)工作距離:0.40mm PLL100X0.85(Dry)(Work distance):0.40 mm |
|||
|
DZ-8MA(配明/暗場物鏡) Equipped with bright & dark fieldobjectives |
PL L5X0.12 BD 工作距離:8.05 mm PLL5X0.12 BD(Work distance):8.05mm |
||
|
PLL10X0.25 BD工作距離:7.86mm PLL10X0.25 BD(Work distance):7.86 mm |
|||
|
PLL20X0.40 BD工作距離:7.23mm PLL20X0.40 BD(Work distance):7.23mm |
|||
|
PLL50X0.70 BD工作距離:2.50mm PLL50X0.70BD (Work distance):2.50mm |
|||
|
目鏡筒 Eyepiece tube |
45°傾斜,瞳距調節范圍53~75mm. Inclination angle is 45"and interpupillary distance is 53~75mm. |
||
|
調焦機構 Focus system |
粗微動同軸調焦,帶鎖緊裝置,微動格值:2um. Coaxial coarse/fne focus, with tension adjustable, minimum divsion of fine focusing is 2ym. |
||
|
轉換器 Nosepiece |
五孔(內向式滾珠內定位)Quintuple(Backward ball bearing inner locating) |
||
|
載物臺 Stage |
機械移動載物臺，外形尺寸:242mmX200mm，移動范圍30mmX30mm. Mechanical stage overall size: 242mmX200mm and movng range : 30mmX30mm. |
||
|
圓形可旋轉載物臺板尺寸:最大外徑Ф130mm，最小通光口徑小于中20mm. Rotundity and rotatable stage size: maximal measurement is $130mm and minimal clear aperture is less then 中20mm |
|||
|
照明系統 lllumination system |
DZ-8 |
6V30W鹵素燈，亮度可調6V30W 6V30W halogen and brightness enable control |
|
|
DZ-8MA |
12V50W鹵素燈，亮度可調12V50W 12V50W halogen and brightness enable control |
||
|
內置視場光闌、孔徑光闌與拉板式起偏器 Integrated feld diaphragm , aperture diaphragm and puller type polarizer. |
|||
|
配磨砂玻璃，黃、綠、藍濾色片 Equipped with frosted glass and yellow ,green and blue filters |
|||
|
選配件 Optional accessories |
目鏡 Eyepiece |
分劃目鏡10X(Ф22mm) |
|
|
物鏡:Objective |
DZ-8 |
5X、40X、60X、80X、100X(油Oil)明場物鏡 Equipped with bright feld objectives |
|
|
DZ-8MA |
40X60X80X、100X明月/暗場物鏡 Equipped with bright & dark field objectives |
||
|
CCD接頭 CCD Adapter |
0.5X、1X |
||
|
攝像儀 Camera |
USB輸出:130/300/500/1000萬像素
USB output 1.3M,3.0M,5.0M,10M pixel |
||
|
VIDEO輸出:380/520電視線
video output 380/520 TV line |
|||
|
數碼相機接頭 Digital camera adapter |
CANON(EF) NIKON( F) |
||
